1776300-6
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description
Barrier Terminal Blocks EUROPA T/BL 10MM
PDF
/
Inventory: 5335
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Current Rating (Max) 30A
Number of Wire Entries 12
Thread Size M3
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 24 AWG
Number of Levels 1
Number of Circuits 6
ELV Compliant
Voltage 600V
Housing Color Natural
Number of Contacts 12
Current Rating 30A
Orientation Straight
Pitch 10.0076mm
Voltage - Rated 600V
Number of Rows 1
Color Natural
Min Operating Temperature -35°C
Max Operating Temperature 100°C
Number of Positions 6
Termination Screw
Packaging Bulk
Physical
Terminal Material Brass
Housing Material Polyamide
Insulation Material Nylon
Mount Panel
Contact Plating Tin
Contact Material Brass
