1546174-7

TE Connectivity
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description Terminal Barrier Block
PDF
/
Inventory: 1453
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Number of Levels 1
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 12 AWG
Number of Wire Entries 15
Current Rating (Max) 25A
Number of Circuits 15
ELV Compliant
Voltage 300V
Housing Color Black
Number of Contacts 15
Current Rating 25A
Orientation Right Angle
Pitch 9.53mm
Voltage - Rated 300V
Number of Rows 1
Color Black
Number of Positions 15
Termination Solder
Part Status Discontinued
Published 2007
Packaging Bulk

Dimensions

Length 144.4244mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0

Physical

Housing Material Polyamide
Insulation Material Nylon
Mount Cable, Chassis, Panel, Through Hole

Supply Chain

Factory Lead Time 8 Weeks
