RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description Fixed Terminal Blocks G 10/ 5
PDF
/
Buying Options
Total Price: USD $25.49
Unit Price: USD $25.4936
≥1 USD $25.4936
≥10 USD $23.45464
≥100 USD $21.670352
≥500 USD $20.650608
≥1000 USD $19.474963
Inventory: 114
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 4 Weeks

Physical

Contact Material Copper
Mount Chassis, Panel, Surface Mount
Mounting Type Chassis, Panel
Material Polyamide
Weight 89.500011g
Material - Insulation Polyamide (PA), Nylon

Technical

Packaging Bulk
Published 2011
Series G
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Screw
ECCN Code EAR99
Number of Positions 10
Color Gray
Number of Rows 2
Voltage - Rated 60V
Current Rating 65A
Wire Gauge 6-24 AWG
Number of Circuits 5
Max Current Rating 76A
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 6 AWG
Wire/Cable Gauge 8 AWG
Number of Decks 1
Terminal Block Type Barrier Block
Bottom Termination Closed
Barrier Type Enclosed
Top Termination Screws
Number of Ways 10
Safety Approval UL

Dimensions

Height 33mm
Length 22mm
Width 68mm

Compliance

Material Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Lead Free
