OSTYK21113030
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description
OSTYK21 ROHS3Compliant PC Pin 8536.69.40.40 Terminal Block Barrier Block UL94V-0 22AWG -40C~105C 10A
PDF
/
Inventory: 7644
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Material - Insulation Polyamide (PA66), Nylon 6/6
Terminal Screw Material Steel
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Series OSTYK21
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Color Black
Number of Rows 1
Voltage - Rated 250V
Additional Feature STANDARD: UL 94V-0, POLYAMIDE66
HTS Code 8536.69.40.40
Pitch 0.250 6.35mm
Current Rating 10A
Wire Gauge 18-22 AWG
Number of Circuits 13
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 18 AWG
Number of Decks 1
Terminal Block Type Barrier Block
Bottom Termination PC Pin
Barrier Type 2 Wall (Dual)
Top Termination Screws with Captive Plate
Number of Ways 13
Safety Approval UL
Terminal Screw Finish Nickel
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
