B48431000
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description
Magnum? B4000 Non-RoHS Compliant 2014 Flange Terminal Block Barrier Block -40C~105C 50A 600V 0.562 14.27mm
PDF
/
Buying Options
Total Price: USD $52.45
Unit Price: USD $52.449042
≥1 USD $52.449042
≥200 USD $20.927626
≥500 USD $20.229163
≥1000 USD $19.882558
Inventory: 6573
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Chassis, Panel
Material - Insulation Thermoplastic
Terminal Screw Material Steel
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Published 2014
Series Magnum? B4000
Feature Flange
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Color Black
Number of Rows 1
Voltage - Rated 600V
Current Rating (Amps) 50A
Pitch 0.562 14.27mm
Wire Gauge 8-16 AWG
Number of Circuits 10
Terminal Block Type Barrier Block
Bottom Termination Screw
Barrier Type 2 Wall (Dual)
Top Termination Screws with Captive Plate
Terminal Screw Finish Zinc
Number of Wire Entries 10
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
