RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description Terminal Barrier Block
PDF
/
Inventory: 7874
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0

Technical

Number of Wire Entries 12
Terminal Screw Finish Nickel
Top Termination Screws with Captive Plate
Barrier Type 2 Wall (Dual)
Bottom Termination Threaded, Insulated
Terminal Block Type Barrier Block
Number of Circuits 12
Wire Gauge 8-16 AWG
Pitch 0.562 14.27mm
Current Rating (Amps) 50A
Voltage - Rated 150V
Number of Rows 1
Color Black
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Flange
Series Magnum? A4000
Published 2014
Packaging Bulk
Operating Temperature -40°C~105°C

Physical

Terminal Screw Material Brass
Material - Insulation Thermoplastic
Mounting Type Chassis, Panel

Supply Chain

Factory Lead Time 6 Weeks
