A38220604
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description
A38 Non-RoHS Compliant 1999 PC Pin Terminal Block Barrier Block UL94V-0 22AWG 105C 30A
PDF
/
Inventory: 9426
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 453.59237mg
Material - Insulation Thermoplastic
Terminal Screw Material Brass
Technical
Operating Temperature 105°C
Packaging Bulk
Published 1999
Series A38
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Color Black
Number of Rows 1
Voltage - Rated 600V
Current Rating (Amps) 30A
Pitch 0.437 11.10mm
Current Rating 30A
Wire Gauge 10-22 AWG
Number of Circuits 6
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 10 AWG
Terminal Block Type Barrier Block
Bottom Termination PC Pin
Barrier Type 2 Wall (Dual)
Top Termination Screws
Terminal Screw Finish Nickel
Number of Wire Entries 6
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
