RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description A3000 Non-RoHS Compliant 2014 Straight Terminal Block Barrier Block UL94V-0 22AWG 105C 30A
PDF
/
Inventory: 8405
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0

Technical

Number of Wire Entries 12
Terminal Screw Finish Nickel
Top Termination Screws with Captive Plate
Barrier Type 2 Wall (Dual)
Bottom Termination Quick Connect (0.250), Insulated
Terminal Block Type Barrier Block
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 22 AWG
Number of Circuits 12
Wire Gauge 12-22 AWG
Housing Color Black
Number of Contacts 12
Current Rating 30A
Orientation Straight
Pitch 0.437 11.10mm
Current Rating (Amps) 30A
Voltage - Rated 600V
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Flange
Series A3000
Published 2014
Packaging Bulk
Operating Temperature -40°C~105°C

Physical

Terminal Screw Material Brass
Material - Insulation Thermoplastic
Weight 453.59237mg
Mounting Type Chassis, Panel
Mount Chassis, Panel

Supply Chain

Factory Lead Time 16 Weeks
