A207206R75
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description
A2000 Non-RoHS Compliant 2014 Straight Terminal Block Barrier Block UL94V-0 22AWG 105C 30A
PDF
/
Buying Options
Total Price: USD $6.72
Unit Price: USD $6.721967
≥1 USD $6.721967
≥10 USD $6.341482
≥100 USD $5.982526
≥500 USD $5.643899
≥1000 USD $5.324429
Inventory: 4899
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Weight 453.59237mg
Material - Insulation Thermoplastic
Terminal Screw Material Steel
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Published 2014
Series A2000
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Wrap
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Black
Number of Rows 1
Voltage - Rated 300V
Current Rating (Amps) 30A
Pitch 0.375 9.53mm
Orientation Straight
Current Rating 30A
Number of Contacts 6
Housing Color Black
Wire Gauge 12-22 AWG
Number of Circuits 6
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 12 AWG
Terminal Block Type Barrier Block
Bottom Termination PC Pin
Barrier Type 2 Wall (Dual)
Top Termination Screws
Terminal Screw Finish Zinc
Number of Wire Entries 6
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
