MALQ-8
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description
Terminal Barrier Block
PDF
/
Inventory: 5350
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Technical
Number of Wire Entries 24
Top Termination Screws and Quick Connect Tabs
Barrier Type 2 Wall (Dual)
Bottom Termination Closed
Terminal Block Type Barrier Block
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 22 AWG
Number of Circuits 8
Wire Gauge 12-22 AWG
Current Rating 25A
Pitch 0.500 12.70mm
Number of Rows 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Flange
Series M
Published 2008
Packaging Bulk
Operating Temperature 150°C
Physical
Terminal Screw Material Brass
Material - Insulation Phenol Formaldehyde (Phenolic)
Mounting Type Chassis, Panel
Mount Chassis, Panel
Supply Chain
Factory Lead Time 5 Weeks
