MA-9
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description
M ROHS3Compliant Flange Closed Terminal Block Barrier Block UL94V-0 22AWG 150C 25A
PDF
/
Inventory: 5020
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Chassis, Panel
Material - Insulation Phenol Formaldehyde (Phenolic)
Terminal Screw Material Steel
Terminal Material Steel
Mount Chassis, Panel
Technical
Operating Temperature 150°C
Packaging Bulk
Series M
Feature Flange
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Rows 2
Current Rating (Amps) 25A
Pitch 0.500 12.70mm
Current Rating 25A
Wire Gauge 12-22 AWG
Number of Circuits 9
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 12 AWG
Terminal Block Type Barrier Block
Bottom Termination Closed
Barrier Type 2 Wall (Dual)
Top Termination Screws
Number of Wire Entries 18
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Supply Chain
Factory Lead Time 5 Weeks
