562105170
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description
5600 ROHS3Compliant 2012 Flange Terminal Block Barrier Block UL94V-0 22AWG 150C 600V
PDF
/
Inventory: 9471
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Chassis, Panel, Through Hole
Mounting Type Chassis, Panel; Through Hole
Material - Insulation Phenol Formaldehyde (Phenolic)
Technical
Operating Temperature 150°C
Packaging Bulk
Published 2012
Series 5600
Feature Flange
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Rows 2
Voltage - Rated 600V
Pitch 0.563 14.30mm
Wire Gauge 8-22 AWG
Number of Circuits 17
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 8 AWG
Terminal Block Type Barrier Block
Bottom Termination PC Pin
Barrier Type 2 Wall (Dual)
Top Termination Screws
Number of Wire Entries 34
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
