RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description 5600 ROHS3Compliant 2012 Flange Terminal Block Barrier Block UL94V-0 22AWG 150C 600V
PDF
/
Buying Options
Total Price: USD $31.31
Unit Price: USD $31.310039
≥1 USD $31.310039
≥200 USD $12.493556
≥500 USD $12.076054
≥1000 USD $11.869929
Inventory: 2577
Minimum: 1
-
+

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Technical

Number of Wire Entries 34
Top Termination Screws
Barrier Type 2 Wall (Dual)
Bottom Termination Closed
Terminal Block Type Barrier Block
Wire Gauge (Min) 8 AWG
Wire Gauge (Max) 22 AWG
Number of Circuits 17
Wire Gauge 8-22 AWG
Pitch 0.563 14.30mm
Voltage - Rated 600V
Number of Rows 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Flange
Series 5600
Published 2012
Packaging Bulk
Operating Temperature 150°C

Physical

Material - Insulation Phenol Formaldehyde (Phenolic)
Mounting Type Chassis, Panel
Mount Chassis, Panel

Supply Chain

Factory Lead Time 7 Weeks
