430212-19-0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description
43000 ROHS3Compliant 2008 Flange Terminal Block Barrier Block UL94V-0 22AWG 105C 20A
PDF
/
Inventory: 6930
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Chassis, Panel
Mounting Type Chassis, Panel
Material - Insulation Polypropylene (PP)
Terminal Screw Material Brass
Technical
Operating Temperature 105°C
Packaging Bulk
Published 2008
Series 43000
Feature Flange
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Rows 1
Voltage - Rated 600V
Pitch 0.438 11.12mm
Current Rating 20A
Wire Gauge 12-22 AWG
Number of Circuits 19
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 12 AWG
Terminal Block Type Barrier Block
Bottom Termination Solder Turret
Barrier Type 2 Wall (Dual)
Top Termination Screws
Terminal Screw Finish Nickel
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
