1522-ST
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description
1500 ROHS3Compliant 2003 Straight Terminal Block Barrier Block UL94V-0 12AWG 110C 20A
PDF
/
Inventory: 8863
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Chassis, Panel
Mounting Type Chassis, Panel
Material - Insulation Polyphenylene Oxide (PPO)
Technical
Operating Temperature 110°C
Packaging Bulk
Published 2003
Series 1500
Feature Flange
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Rows 2
Pitch 0.375 9.53mm
Orientation Straight
Current Rating 20A
Wire Gauge 10-22 AWG
Number of Circuits 22
Max Current Rating 20A
Wire/Cable Gauge 12 AWG
Terminal Block Type Barrier Block
Bottom Termination Closed
Barrier Type 2 Wall (Dual)
Top Termination Screws with Solder Lugs, Dual
Terminal Screw Finish Tin
Number of Wire Entries 44
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
