12-141
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description
CONN BARRIER STRP 12CIRC 0.438"
PDF
/
Buying Options
Total Price: USD $9.51
Unit Price: USD $9.5128
≥1 USD $9.5128
≥10 USD $8.3688
≥100 USD $7.8936
≥500 USD $7.513088
≥1000 USD $7.370352
≥3000 USD $6.419354
Inventory: 510
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Brass
Mount Chassis, Panel
Mounting Type Chassis, Panel
Housing Material Phenolic
Material - Insulation Phenol Formaldehyde (Phenolic)
Terminal Screw Material Steel
Technical
Operating Temperature -55°F~300°F
Packaging Bulk
Published 2002
Series 141
Feature Flange
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Screw
ECCN Code EAR99
Connector Type Terminal Block
Color Black
Number of Rows 2
HTS Code 8536.69.40.40
Pitch 0.438 11.12mm
Orientation Straight
Depth 12.7mm
Current Rating 20A
Wire Gauge 14 AWG
Max Voltage Rating (AC) 250V
Max Current Rating 20A
Wire Gauge (Max) 14 AWG
Wire/Cable Gauge 14 AWG
Number of Poles 12
Number of Decks 1
Terminal Block Type Barrier Block
Bottom Termination Closed
Barrier Type 2 Wall (Dual)
Top Termination Screws
Number of Ways 12
Safety Approval UL; CSA
Terminal Screw Finish Nickel
Number of Wire Entries 24
Max Supply Voltage (AC) 250V
Dimensions
Height 12.7mm
Length 152.4mm
Width 28.575mm
Compliance
Material Flammability Rating UL94 V-1
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Flammability Rating UL94 V-1
