TMP392A3DRLR

Texas Instruments
RoHS
RoHS RoHS compliant
Package SOT-563, SOT-666
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description DUAL TRIP TEMPERATURE SWITCH
PDF
/
Buying Options
Total Price: USD $0.59
Unit Price: USD $0.5896
≥1 USD $0.5896
≥10 USD $0.44968
≥100 USD $0.3872
≥500 USD $0.373296
≥1000 USD $0.317944
≥3000 USD $0.276496
Inventory: 1179
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Mounting Type Surface Mount
Package / Case SOT-563, SOT-666
Surface Mount YES

Technical

Operating Temperature -55°C~130°C
JESD-609 Code e4
Feature Selectable Trip Point
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Voltage - Supply 1.62V~5.5V
Terminal Position DUAL
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TMP392
Output Active Low
JESD-30 Code R-PDSO-N6
Output Type Open Drain
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 1.62V
Analog IC - Other Type ANALOG CIRCUIT
Accuracy ±3.5°C
Current - Supply 500nA
Output Function OverTemp
Switching Temperature Programmable
Selectable Hysteresis Yes
Trip Temperature Threshold Hot

Dimensions

Height Seated (Max) 0.6mm
Length 1.6mm
Width 1.2mm

Compliance

RoHS Status ROHS3 Compliant
