TMP303GDRLR
RoHS
RoHS compliant
RoHS compliantPackage SOT-563, SOT-666
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
THERMOSTAT 90DEG ACT HI SOT563-6
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.07445
≥1 USD $1.07445
≥10 USD $0.8816
≥100 USD $0.85405
≥500 USD $0.8265
≥1000 USD $0.79895
Inventory: 12478
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mounting Type Surface Mount
Package / Case SOT-563, SOT-666
Surface Mount YES
Number of Pins 6
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Feature Selectable Hysteresis
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1
Number of Terminations 6
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Voltage - Supply 1.4V~3.6V
Terminal Position DUAL
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TMP303
Output Active High
Output Type Push-Pull
Supply Voltage-Min (Vsup) 1.4V
Number of Channels 1
Analog IC - Other Type ANALOG CIRCUIT
Current - Output (Max) 8mA
Accuracy ±1°C
Current - Supply 4μA
Output Function OverTemp
Switching Temperature 90°C
Selectable Hysteresis Yes
Trip Temperature Threshold Hot
Dimensions
Height 600μm
Length 1.6mm
Width 1.2mm
Thickness 550μm
Compliance
RoHS Status ROHS3 Compliant
