TMP302ADRLT
RoHS
RoHS compliant
RoHS compliantPackage SOT-563, SOT-666
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
TEXAS INSTRUMENTS TMP302ADRLT Temperature Sensor IC, Open Drain,0.2C, -40 C, +125 C, SOT-563, 6 Pins
PDF
/
Buying Options
Total Price: USD $1.14
Unit Price: USD $1.144
≥1 USD $1.144
≥10 USD $0.85624
≥100 USD $0.68464
≥500 USD $0.627704
Inventory: 289
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 550μm
Width 1.2mm
Length 1.6mm
Height 600μm
Technical
Trip Temperature Threshold Hot
Selectable Hysteresis Yes
Switching Temperature 50°C 55°C 60°C 65°C
Min Supply Voltage (DC) 1.4V
Max Supply Voltage (DC) 3.6V
Output Function /OverTemp
Accuracy ±2°C
Quiescent Current 8μA
Output Current 10mA
Nominal Supply Current 8μA
Operating Supply Current 8μA
Analog IC - Other Type ANALOG CIRCUIT
Number of Channels 1
Max Output Current 10mA
Output Type Open Drain
Output Voltage 3.6V
Pin Count 6
Output Active Low
Base Part Number TMP302
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 1.4V~3.6V
HTS Code 8542.39.00.01
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Selectable Trip Point
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 6
Package / Case SOT-563, SOT-666
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
