LM57TPW
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
THERMOSTAT PROG ACT HI/LO 8TSSOP
PDF
/
Buying Options
Total Price: USD $1.56
Unit Price: USD $1.558
≥1 USD $1.558
≥10 USD $1.27775
≥100 USD $1.23785
≥500 USD $1.19795
≥1000 USD $1.15805
Inventory: 1108
Minimum: 1
-
+
Technical Details
Technical
JESD-609 Code e4
Series Automotive, AEC-Q100
Packaging Tube
Operating Temperature -50°C~150°C
Trip Temperature Threshold Hot
Selectable Hysteresis No
Switching Temperature Programmable
Output Function OverTemp, /OverTemp
Accuracy ±2.3°C
Operating Supply Current 24μA
Interface Analog
Number of Channels 1
Supply Voltage-Min (Vsup) 2.4V
Supply Voltage-Max (Vsup) 5.5V
Max Output Current 5mA
Output Type Open Drain, Push-Pull
Output Active High, Active Low
Base Part Number LM57
Terminal Pitch 0.65mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.4V~5.5V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Feature Selectable Trip Point, Trip Test
Physical
Number of Pins 8
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1mm
Width 4.4mm
Length 3mm
Height 1.2mm
