LM57TEPWQ1

Texas Instruments
RoHS
RoHS RoHS compliant
Package 8-TSSOP (0.173, 4.40mm Width)
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description THERMOSTAT PROG ACT HI/LO 8TSSOP
PDF
/
Buying Options
Total Price: USD $2.85
Unit Price: USD $2.8512
≥1 USD $2.8512
≥10 USD $2.32496
≥100 USD $1.886016
≥500 USD $1.754544
≥1000 USD $1.666782
Inventory: 648
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Thickness 1mm
Width 4.4mm
Length 3mm
Height 1.2mm

Technical

Trip Temperature Threshold Hot
Selectable Hysteresis No
Switching Temperature Programmable
Multiplexed Display Capability NO
Number of Segments 1
Output Function OverTemp, /OverTemp
Input Characteristics STANDARD
Accuracy ±2.3°C
Operating Supply Current 24μA
Interface Analog
Max Output Current 5mA
Output Type Open Drain, Push-Pull
Output Active High, Active Low
Base Part Number LM57
Terminal Pitch 0.65mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.4V~5.5V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Feature Selectable Trip Point, Trip Test
JESD-609 Code e4
Series Automotive, AEC-Q100
Packaging Tube
Operating Temperature -50°C~150°C

Physical

Number of Pins 8
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
