LM57FSPWQ1
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
THERMOSTAT PROG ACT HI/LO 8TSSOP
PDF
/
Buying Options
Total Price: USD $2.56
Unit Price: USD $2.559591
≥1 USD $2.559591
≥100 USD $2.075456
≥250 USD $1.47743
≥1000 USD $1.095869
Inventory: 1137
Minimum: 1
-
+
Technical Details
Technical
Terminal Pitch 0.65mm
Base Part Number LM57
Output Active High, Active Low
Output Type Open Drain, Push-Pull
Max Output Current 5mA
Interface Analog
Operating Supply Current 26μA
Accuracy ±2.3°C
Input Characteristics STANDARD
Output Function OverTemp, /OverTemp
Number of Segments 1
Multiplexed Display Capability NO
Switching Temperature Programmable
Selectable Hysteresis No
Trip Temperature Threshold Hot
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.4V~5.5V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Feature Selectable Trip Point, Trip Test
JESD-609 Code e4
Series Automotive, AEC-Q100
Packaging Tube
Operating Temperature -50°C~160°C
Dimensions
Height 1.2mm
Length 3mm
Width 4.4mm
Thickness 1mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 8
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
