LM57CISD-5/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 8-WFDFN Exposed Pad
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
THERMOSTAT PROG ACT HI/LOW 8WSON
PDF
/
Buying Options
Total Price: USD $1.21
Unit Price: USD $1.2084
≥1 USD $1.2084
≥10 USD $0.9918
≥100 USD $0.96045
≥500 USD $0.93005
≥1000 USD $0.8987
Inventory: 84531
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-WFDFN Exposed Pad
Number of Pins 8
Technical
Operating Temperature -50°C~150°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Feature Selectable Trip Point, Trip Test
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
ECCN Code EAR99
Voltage - Supply 2.4V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.5mm
Base Part Number LM57
Output Active High, Active Low
Output Type Open Drain, Push-Pull
Number of Channels 1
Interface Analog
Operating Supply Current 24μA
Nominal Supply Current 24μA
Output Current 5mA
Quiescent Current 24μA
Accuracy ±2.3°C
Output Function OverTemp, /OverTemp
Max Supply Voltage (DC) 5.5V
Min Supply Voltage (DC) 2.4V
Switching Temperature Programmable
Selectable Hysteresis Yes
Trip Temperature Threshold Hot
Dimensions
Height 800μm
Length 2.5mm
Width 2.5mm
Thickness 800μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
