LM26CIM5-VHA
RoHS
/
Package SC-74A, SOT-753
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
THERMOSTAT 90DEGC ACT LO SOT23-5
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.3414
≥1 USD $1.3414
≥10 USD $1.10105
≥100 USD $1.0659
≥500 USD $1.0317
≥1000 USD $0.9975
Inventory: 18006
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 1.6mm
Length 2.92mm
Height 1.02mm
Technical
Trip Temperature Threshold Hot
Selectable Hysteresis Yes
Switching Temperature 90°C
Housing PLASTIC
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SINGLE TRIP POINT
Output Function /OverTemp
Accuracy ±3°C
Quiescent Current 40μA
Nominal Supply Current 20μA
Operating Supply Current 16μA
Output Type Open Drain
Output Voltage 5.5V
Output Active Low
Base Part Number LM26
Voltage - Supply 2.7V~5.5V
Subcategory Other Sensors/Transducers
Additional Feature CMOS COMPATIBLE
Terminal Finish Tin/Lead (Sn/Pb)
Temperature Coefficient NEGATIVE/POSITIVE ppm/°C
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount
