TC653CGVUATR

Microchip Technology
RoHS
RoHS RoHS compliant
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description Tape & Reel (TR) Active Low Automatic Fan Shutdown Fan Controller 8 35°C 55°C Thermostat 3mm 50muA 2.8V~5.5V -40C~125C
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.2224
≥1 USD $3.2224
≥10 USD $2.64385
≥100 USD $2.5612
≥500 USD $2.47855
≥1000 USD $2.3959
Inventory: 72
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Body Height 1.1mm

Technical

Trip Temperature Threshold Hot
Selectable Hysteresis No
Switching Temperature 35°C 55°C
Housing PLASTIC
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SINGLE TRIP POINT
Output Function /Fault, /OverTemp, PWM
Current - Supply 50μA
Accuracy ±2.5°C
Output Current 5mA
Nominal Supply Current 90μA
Termination Type SOLDER
Body Breadth 3 mm
Body Length or Diameter 3mm
Output Active Low
Voltage - Supply 2.8V~5.5V
Additional Feature PWM OUTPUT
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Automatic Fan Shutdown, Fan Controller
JESD-609 Code e3
Published 2002
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
