TC652AGVUA image
Favorite
TC652AGVUA image
Favorite
RoHS
RoHS RoHS compliant
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description MICROCHIP TC652AGVUA IC, TEMP SENSOR, FAN, CTRLR, 8MSOP
PDF
/
Buying Options
Total Price: USD $2.13
Unit Price: USD $2.1296
≥1 USD $2.1296
≥10 USD $1.7776
≥100 USD $1.6192
Inventory: 443
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Technical

Trip Temperature Threshold Hot
Selectable Hysteresis No
Switching Temperature 25°C 55°C
Housing PLASTIC
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SINGLE TRIP POINT
Output Function /Fault, /OverTemp, PWM
Current - Supply 50μA
Accuracy ±2.5°C
Output Current 5mA
Output Configuration Pulse
Nominal Supply Current 90μA
Termination Type SOLDER
Number of Channels 1
Output Voltage 2.3V
Body Breadth 3 mm
Body Length or Diameter 3mm
Output Active Low
Base Part Number TC652
Voltage - Supply 2.8V~5.5V
Additional Feature PWM OUTPUT
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Fan Controller
JESD-609 Code e3
Published 2002
Packaging Tube
Operating Temperature -40°C~125°C

Physical

Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
