TC651AEVUATR
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
TC651AE Series 5.5 V -25 to +70°C Temp Sensor/DC Fan Control - MSOP-8 T/R
PDF
/
Buying Options
Total Price: USD $1.36
Unit Price: USD $1.360164
≥1 USD $1.360164
≥200 USD $0.526473
≥500 USD $0.508092
≥1000 USD $0.498902
Inventory: 8462
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Trip Temperature Threshold Hot
Selectable Hysteresis No
Switching Temperature 25°C 45°C
Housing PLASTIC
Output Function /Fault, /OverTemp, PWM
Accuracy ±3°C
Output Current 5mA
Operating Supply Current 50μA
Termination Type SOLDER
Max Output Current 90μA
Output Type Digital
Body Breadth 3 mm
Body Length or Diameter 3mm
Output Active Low
Voltage - Supply 2.8V~5.5V
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Automatic Fan Shutdown, Fan Controller
JESD-609 Code e3
Published 2004
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
