TC6502P125VCTTR
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
SWITCH, TEMPERATURE 125C, SOT-23A-5
PDF
/
Buying Options
Total Price: USD $0.85
Unit Price: USD $0.8536
≥1 USD $0.8536
≥10 USD $0.7128
≥100 USD $0.6424
Inventory: 1130
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 1.8mm
Length 3.1mm
Height 1.3mm
Technical
Trip Temperature Threshold Hot
Selectable Hysteresis Yes
Switching Temperature 125°C
Min Supply Voltage (DC) 2.7V
Max Supply Voltage (DC) 5.5V
Output Function OverTemp
Sensor Type Temperature
Accuracy ±6°C
Output Current 20mA
Nominal Supply Current 17μA
Operating Supply Current 17μA
Analog IC - Other Type ANALOG CIRCUIT
Max Output Current 20mA
Output Type Push-Pull
Output Voltage 2.16V
Pin Count 5
Output Active High
Base Part Number TC650
Time@Peak Reflow Temperature-Max (s) 40
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2004
Packaging Tape & Reel (TR)
Operating Temperature -55°C~135°C
Physical
Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
