TC6501P120VCTTRG
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
IC TEMP SWTCH OPEN DRAIN SOT23-5
PDF
/
Buying Options
Total Price: USD $0.65
Unit Price: USD $0.6512
≥1 USD $0.6512
≥10 USD $0.5588
≥100 USD $0.524128
≥500 USD $0.484
Inventory: 1180
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 1.63mm
Length 2.95mm
Height Seated (Max) 1.45mm
Technical
Trip Temperature Threshold Hot
Selectable Hysteresis Yes
Switching Temperature 120°C
Min Supply Voltage (DC) 2.7V
Max Supply Voltage (DC) 5.5V
Output Function /OverTemp
Accuracy ±6°C
Operating Supply Current 17μA
Analog IC - Other Type ANALOG CIRCUIT
Max Output Current 20mA
Output Type Open Drain
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G5
Pin Count 5
Output Active Low
Base Part Number TC650
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.95mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2004
Packaging Tape & Reel (TR)
Operating Temperature -55°C~135°C
Physical
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount
