TC6501P045VCTTR

Microchip Technology
RoHS
RoHS RoHS compliant
Package SC-74A, SOT-753
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description SWITCH, TEMPERATURE 45C, SOT-23A-5
PDF
/
Buying Options
Total Price: USD $0.85
Unit Price: USD $0.8536
≥1 USD $0.8536
Inventory: 106
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Width 2.9972mm
Length 3.0988mm
Height 1.2954mm

Technical

Trip Temperature Threshold Hot
Selectable Hysteresis Yes
Switching Temperature 45°C
Min Supply Voltage (DC) 2.7V
Max Supply Voltage (DC) 5.5V
Output Function /OverTemp
Sensor Type Temperature
Accuracy ±6°C
Output Current 20mA
Nominal Supply Current 17μA
Operating Supply Current 17μA
Analog IC - Other Type ANALOG CIRCUIT
Max Output Current 20mA
Output Type Open Drain
Pin Count 5
Output Active Low
Base Part Number TC650
Time@Peak Reflow Temperature-Max (s) 40
Supply Voltage 2.7V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
Max Power Dissipation 570mW
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2004
Packaging Tape & Reel (TR)
Operating Temperature -55°C~135°C

Physical

Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 13 Weeks
