TC624CPA
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
THERMOSTAT PROG ACT HI/LOW 8DIP
PDF
/
Buying Options
Total Price: USD $1.26
Unit Price: USD $1.256445
≥1 USD $1.256445
≥200 USD $0.487086
≥500 USD $0.470018
≥1000 USD $0.460828
Inventory: 7406
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Number of Pins 8
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 2006
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Temperature Coefficient NEGATIVE/POSITIVE ppm/°C
Terminal Finish Matte Tin (Sn)
Subcategory Other Sensors
Voltage - Supply 2.7V~4.5V
Base Part Number TC624
Output Active High, Active Low
Body Length or Diameter 9.5mm
Body Breadth 7.62 mm
Output Type Push-Pull
Operating Supply Voltage 3.3V
Termination Type SOLDER
Operating Supply Current 170μA
Output Current 300μA
Accuracy ±5°C
Output Function OverTemp, /OverTemp
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SINGLE TRIP POINT
Max Supply Voltage (DC) 4.5V
Min Supply Voltage (DC) 2.7V
Housing PLASTIC
Switching Temperature Programmable
Selectable Hysteresis No
Trip Temperature Threshold Hot
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
