TC624COA
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
Temp Sensor Analog 8-Pin SOIC N Tube
PDF
/
Buying Options
Total Price: USD $21.48
Unit Price: USD $21.47855
≥1 USD $21.47855
≥10 USD $17.62345
≥100 USD $17.07245
≥500 USD $16.5224
≥1000 USD $15.9714
Inventory: 108
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Body Height 1.72mm
Technical
Trip Temperature Threshold Hot
Selectable Hysteresis No
Switching Temperature Programmable
Housing PLASTIC
Min Supply Voltage (DC) 2.7V
Max Supply Voltage (DC) 4.5V
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SINGLE TRIP POINT
Output Function OverTemp, /OverTemp
Accuracy ±5°C
Output Current 300μA
Operating Supply Current 170μA
Termination Type SOLDER
Operating Supply Voltage 3.3V
Output Type Push-Pull
Body Breadth 3.9 mm
Output Active High, Active Low
Base Part Number TC624
Voltage - Supply 2.7V~4.5V
Subcategory Other Sensors
Terminal Finish Matte Tin (Sn)
Temperature Coefficient NEGATIVE/POSITIVE ppm/°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2006
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
