TC622VAT image
Favorite
TC622VAT image
Favorite
RoHS
RoHS RoHS compliant
Package TO-220-5
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description THERMOSTAT PROG ACT HIGH TO220-5
PDF
/
Buying Options
Total Price: USD $2.2
Unit Price: USD $2.2
≥1 USD $2.2
≥10 USD $1.8392
≥100 USD $1.771
Inventory: 1154
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Surface Mount, Through Hole
Mounting Type Through Hole
Package / Case TO-220-5
Number of Pins 5

Technical

Operating Temperature -40°C~125°C
Packaging Bulk
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
Termination Through Hole
ECCN Code EAR99
Temperature Coefficient NEGATIVE/POSITIVE ppm/°C
Terminal Finish Matte Tin (Sn)
Subcategory Other Sensors
Voltage - Supply 4.5V~18V
Base Part Number TC622
Output Active High
Output Type Push-Pull
Operating Supply Current 600μA
Output Current 600μA
Accuracy ±5°C
Sensor Type Temperature
Output Function OverTemp, /OverTemp
Max Supply Voltage (DC) 18V
Min Supply Voltage (DC) 4.5V
Housing PLASTIC
Switching Temperature Programmable
Selectable Hysteresis No
Trip Temperature Threshold Hot

Dimensions

Height 9.02mm
Length 10.67mm
Width 4.83mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
