TC621HCOA713
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
Tape & Reel (TR) Active Low 8 TC621 Programmable Thermostat 3.9mm 1mA 4.5V~18V 0C~70C
PDF
/
Buying Options
Total Price: USD $1.04
Unit Price: USD $1.042443
≥1 USD $1.042443
≥200 USD $0.404373
≥500 USD $0.389931
≥1000 USD $0.383367
Inventory: 8814
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Body Height 1.72mm
Technical
Trip Temperature Threshold Cold Hot
Selectable Hysteresis Yes
Switching Temperature Programmable
Housing PLASTIC
Min Supply Voltage (DC) 4.5V
Max Supply Voltage (DC) 18V
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,DUAL TRIP POINT
Output Function /OverTemp, /UnderTemp
Accuracy ±3°C
Output Current 1mA
Operating Supply Current 270μA
Termination Type SOLDER
Max Output Current 1mA
Output Type Push-Pull
Body Breadth 3.9 mm
Output Active Low
Base Part Number TC621
Voltage - Supply 4.5V~18V
Max Power Dissipation 470mW
Subcategory Other Sensors/Transducers
Terminal Finish Matte Tin (Sn)
Temperature Coefficient NEGATIVE ppm/°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
