TC621CEOA713
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
IC TEMP SNSR 5V DUAL TRIP 8-SOIC
PDF
/
Buying Options
Total Price: USD $2.36
Unit Price: USD $2.36265
≥1 USD $2.36265
≥10 USD $1.93895
≥100 USD $1.87815
≥500 USD $1.8183
≥1000 USD $1.7575
Inventory: 20
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Body Height 1.72mm
Technical
Trip Temperature Threshold Cold Hot
Selectable Hysteresis Yes
Switching Temperature Programmable
Housing PLASTIC
Min Supply Voltage (DC) 4.5V
Max Supply Voltage (DC) 18V
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,DUAL TRIP POINT
Output Function /OverTemp, /UnderTemp
Accuracy ±3°C
Output Current 1mA
Operating Supply Current 400μA
Termination Type SOLDER
Max Output Current 1mA
Output Type Push-Pull
Body Breadth 3.9 mm
Output Active High
Base Part Number TC621
Voltage - Supply 4.5V~18V
Max Power Dissipation 470mW
Subcategory Other Sensors/Transducers
Terminal Finish Matte Tin (Sn)
Temperature Coefficient NEGATIVE ppm/°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
