TC620HEOA713
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
IC TEMP SNSR 5V DUAL TRIP 8-SOIC
PDF
/
Buying Options
Total Price: USD $1.62
Unit Price: USD $1.617493
≥1 USD $1.617493
≥200 USD $0.626253
≥500 USD $0.603934
≥1000 USD $0.593431
Inventory: 8426
Minimum: 1
-
+
Technical Details
Technical
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,DUAL TRIP POINT
Max Supply Voltage (DC) 18V
Min Supply Voltage (DC) 4.5V
Housing PLASTIC
Switching Temperature Programmable
Selectable Hysteresis Yes
Trip Temperature Threshold Cold Hot
Output Function OverTemp, UnderTemp
Accuracy ±3°C
Output Current 1mA
Operating Supply Current 270μA
Termination Type SOLDER
Max Output Current 1mA
Output Type Push-Pull
Body Breadth 3.9 mm
Output Active High
Base Part Number TC620
Voltage - Supply 4.5V~18V
Max Power Dissipation 470mW
Subcategory Other Sensors/Transducers
Terminal Finish Matte Tin (Sn)
Temperature Coefficient POSITIVE ppm/°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2002
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Dimensions
Body Height 1.72mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
