TC620HCPA
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
THERMOSTAT PROG ACTIVE HIGH 8DIP
PDF
/
Buying Options
Total Price: USD $1.19
Unit Price: USD $1.189487
≥1 USD $1.189487
≥200 USD $0.460828
≥500 USD $0.445073
≥1000 USD $0.437196
Inventory: 962
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Trip Temperature Threshold Cold Hot
Selectable Hysteresis Yes
Switching Temperature Programmable
Housing PLASTIC
Min Supply Voltage (DC) 4.5V
Max Supply Voltage (DC) 18V
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,DUAL TRIP POINT
Output Function OverTemp, UnderTemp
Accuracy ±3°C
Output Current 1mA
Operating Supply Current 270μA
Termination Type SOLDER
Max Output Current 1mA
Output Type Push-Pull
Body Breadth 7.62 mm
Body Length or Diameter 9.5mm
Output Active High
Base Part Number TC620
Voltage - Supply 4.5V~18V
Max Power Dissipation 730mW
Subcategory Other Sensors/Transducers
Terminal Finish Matte Tin (Sn)
Temperature Coefficient POSITIVE ppm/°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2002
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 7 Weeks
