TC620CEPA
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
THERMOSTAT PROG ACTIVE HIGH 8DIP
PDF
/
Buying Options
Total Price: USD $1.94
Unit Price: USD $1.9448
≥1 USD $1.9448
≥10 USD $1.6368
≥100 USD $1.573
Inventory: 236
Minimum: 1
-
+
Technical Details
Technical
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
JESD-609 Code e3
Published 1998
Packaging Tube
Operating Temperature -40°C~85°C
Trip Temperature Threshold Cold Hot
Selectable Hysteresis Yes
Switching Temperature Programmable
Housing PLASTIC
Min Supply Voltage (DC) 4.5V
Max Supply Voltage (DC) 18V
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,DUAL TRIP POINT
Output Function OverTemp, UnderTemp
Accuracy ±3°C
Output Current 1mA
Nominal Supply Current 270μA
Operating Supply Current 270μA
Termination Type SOLDER
Max Output Current 1mA
Output Type Push-Pull
Body Breadth 7.62 mm
Output Active High
Base Part Number TC620
Voltage - Supply 4.5V~18V
Max Power Dissipation 730mW
Subcategory Other Sensors/Transducers
Terminal Finish Matte Tin (Sn)
Temperature Coefficient POSITIVE ppm/°C
ECCN Code EAR99
Number of Terminations 8
Physical
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 7 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 6.6mm
Length 10.16mm
Height 2.54mm
