MCP9509HT-E/OT
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
MICROCHIP - MCP9509HT-E/OT - TEMPERATURE SWITCH, 0.5?C, SOT23-5, FULL REEL
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.924
≥1 USD $0.924
≥10 USD $0.7744
≥100 USD $0.7128
Inventory: 30947
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Number of Pins 5
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2008
JESD-609 Code e3
Feature Selectable Trip Point
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Voltage - Supply 2.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) 40
Output Active Low
Pin Count 5
Output Voltage 5.5V
Output Type Open Drain
Max Output Current 20mA
Supply Voltage-Min (Vsup) 2.7V
Analog IC - Other Type ANALOG CIRCUIT
Operating Supply Current 30μA
Impedance 500kOhm
Nominal Supply Current 30μA
Output Current 20mA
Accuracy ±0.5°C
Sensor Type Temperature
Output Function /OverTemp
Switching Temperature Programmable
Selectable Hysteresis Yes
Trip Temperature Threshold Hot
Dimensions
Height 1.2954mm
Length 3.0988mm
Width 1.8034mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
