MAX6687AU75H+
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
Board Mount Temperature Sensors Local/Remote Temperature Switch
PDF
/
Buying Options
Total Price: USD $1.14
Unit Price: USD $1.142387
≥1 USD $1.142387
≥10 USD $1.077723
≥100 USD $1.016722
≥500 USD $0.959176
≥1000 USD $0.90488
Inventory: 8250
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 1.1mm
Technical
Trip Temperature Threshold Hot
Selectable Hysteresis No
Switching Temperature 75°C~115°C 125°C
Min Supply Voltage (DC) 3V
Max Supply Voltage (DC) 5.5V
Output Function /OverTemp
Accuracy ±5°C
Nominal Supply Current 215μA
Operating Supply Current 215μA
Analog IC - Other Type ANALOG CIRCUIT
Max Output Current 20mA
Output Type Open Drain
Pin Count 8
Output Active Low
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Technology BICMOS
Terminal Finish Matte Tin (Sn)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Selectable Trip Point
JESD-609 Code e3
Published 2003
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
