MAX6670AUB50+
RoHS
RoHS compliant
RoHS compliantPackage 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
THERMOSTAT 50DEGC ACT LOW 10UMAX
PDF
/
Inventory: 4153
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Surface Mount
Package / Case 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2002
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.39.00.01
Technology BICMOS
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Output Active Low
Pin Count 10
JESD-30 Code S-PDSO-G10
Qualification Status Not Qualified
Output Type Open Drain
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Interface Logic
Analog IC - Other Type ANALOG CIRCUIT
Current - Output (Max) 250mA
Accuracy ±2.2°C
Current - Supply 110μA
Output Function /FanOut, /OverTemp, /Warn
Switching Temperature 50°C
Selectable Hysteresis Yes
Trip Temperature Threshold Hot
Dimensions
Height Seated (Max) 1.1mm
Length 3mm
Width 3mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
