MAX6665ASA70+
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
THERMOSTAT 70DEG ACT HI/LO 8SOIC
PDF
/
Buying Options
Total Price: USD $3.5
Unit Price: USD $3.502342
≥1 USD $3.502342
≥10 USD $3.304099
≥100 USD $3.117073
≥500 USD $2.940636
≥1000 USD $2.774184
Inventory: 1166
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Trip Temperature Threshold Hot
Selectable Hysteresis Yes
Switching Temperature 70°C
Output Function FanOn, /FanOut, /OverTemp, /Warn
Supply Current-Max (Isup) 0.2mA
Accuracy ±3°C
Output Current 250mA
Nominal Supply Current 65μA
Operating Supply Current 65μA
Analog IC - Other Type ANALOG CIRCUIT
Interface Logic
Supply Voltage-Min (Vsup) 2.7V
Power Supplies 3/5V
Operating Supply Voltage 5.5V
Max Output Current 250mA
Output Type Open Drain, Push-Pull
Output Voltage 24V
Pin Count 8
Output Active High, Active Low
Base Part Number MAX6665
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
Technology BICMOS
Subcategory Motion Control Electronics
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2001
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
