MAX6514UKN015+T
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
THERMOSTAT 15DEGC ACT HI SOT23-5
PDF
/
Inventory: 1876
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case SC-74A, SOT-753
Surface Mount YES
Number of Pins 5
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2011
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
Terminal Finish Matte Tin (Sn)
Technology BICMOS
Voltage - Supply 2.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) 40
Output Active High
Pin Count 5
Output Type Push-Pull
Operating Supply Voltage 5.5V
Supply Voltage-Min (Vsup) 2.7V
Interface Logic
Analog IC - Other Type ANALOG CIRCUIT
Operating Supply Current 40μA
Accuracy ±1.5°C
Output Function /UnderTemp
Switching Temperature -15°C
Selectable Hysteresis Yes
Trip Temperature Threshold Cold
Dimensions
Length 2.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
