MAX6509HAUK-T
RoHS
/
Package SC-74A, SOT-753
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
Tape & Reel (TR) Active Low Selectable Trip Point 1 Programmable Thermostat 2.9mm 20mA 2.7V~5.5V -40C~125C
PDF
/
Buying Options
Total Price: USD $2.64
Unit Price: USD $2.6353
≥1 USD $2.6353
≥10 USD $2.1622
≥100 USD $2.09475
≥500 USD $2.0273
≥1000 USD $1.95985
Inventory: 10303
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Surface Mount YES
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2003
JESD-609 Code e0
Feature Selectable Trip Point
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Voltage - Supply 2.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.95mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Output Active Low
Pin Count 5
JESD-30 Code R-PDSO-G5
Qualification Status Not Qualified
Output Type Open Drain
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.7V
Number of Channels 1
Interface Logic
Analog IC - Other Type ANALOG CIRCUIT
Current - Output (Max) 20mA
Accuracy ±4.7°C
Current - Supply 32μA
Output Function /OverTemp
Switching Temperature Programmable
Selectable Hysteresis Yes
Trip Temperature Threshold Hot
Dimensions
Length 2.9mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
