MAX6506UTP080+

Maxim Integrated
RoHS
RoHS RoHS compliant
Package SOT-23-6
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description THERMOSTAT 80DEGC ACT HI SOT23-6
PDF
/
Inventory: 6992
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Surface Mount
Package / Case SOT-23-6
Surface Mount YES

Technical

Operating Temperature -40°C~125°C
Published 2011
Feature Delta Select Inputs
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
HTS Code 8542.39.00.01
Technology BICMOS
Voltage - Supply 2.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.95mm
Output Active High
Pin Count 6
JESD-30 Code R-PDSO-G6
Output Type Push-Pull
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.5V
Analog IC - Other Type ANALOG CIRCUIT
Current - Output (Max) 20mA
Accuracy ±3.5°C
Current - Supply 40μA
Output Function /OverTemp, /Warn
Switching Temperature 80°C
Selectable Hysteresis No
Trip Temperature Threshold Hot

Dimensions

Height Seated (Max) 1.45mm
Length 2.9mm
Width 1.625mm

Compliance

RoHS Status ROHS3 Compliant
