MAX6505UTP105+

Maxim Integrated
RoHS
RoHS RoHS compliant
Package SOT-23-6
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description THERMOSTAT 105DEG ACT LO SOT23-6
PDF
/
Inventory: 6876
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Length 2.9mm
Height Seated (Max) 1.45mm

Technical

Trip Temperature Threshold Hot
Selectable Hysteresis No
Switching Temperature 105°C
Output Function /OverTemp, /Warn
Current - Supply 40μA
Accuracy ±4°C
Current - Output (Max) 20mA
Analog IC - Other Type ANALOG CIRCUIT
Supply Voltage-Min (Vsup) 2.5V
Operating Supply Voltage 5.5V
Output Type Open Drain
Pin Count 6
Output Active Low
Terminal Pitch 0.95mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.5V~5.5V
Technology BICMOS
HTS Code 8542.39.00.01
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Delta Select Inputs
JESD-609 Code e4
Published 2011
Operating Temperature -40°C~125°C

Physical

Number of Pins 6
Package / Case SOT-23-6
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 98 Weeks
