MAX6505UTN035+T
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
IC TEMP SWITCH DL TRIP SOT23-6
PDF
/
Inventory: 9102
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 1.625mm
Length 2.9mm
Height Seated (Max) 1.45mm
Technical
Trip Temperature Threshold Hot
Selectable Hysteresis No
Switching Temperature -35°C
Output Function /OverTemp, /Warn
Current - Supply 40μA
Accuracy ±5.5°C
Current - Output (Max) 20mA
Analog IC - Other Type ANALOG CIRCUIT
Interface Logic
Supply Voltage-Min (Vsup) 2.5V
Supply Voltage-Max (Vsup) 5.5V
Output Type Open Drain
JESD-30 Code R-PDSO-G6
Pin Count 6
Output Active Low
Terminal Pitch 0.95mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.5V~5.5V
Technology BICMOS
HTS Code 8542.39.00.01
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Delta Select Inputs
JESD-609 Code e4
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case SOT-23-6
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 25 Weeks
