MAX6502UKP075+T
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
THERMOSTAT 75DEGC ACT HI SOT23-5
PDF
/
Inventory: 7311
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 1.625mm
Length 2.9mm
Height Seated (Max) 1.45mm
Technical
Trip Temperature Threshold Hot
Selectable Hysteresis Yes
Switching Temperature 75°C
Output Function OverTemp
Current - Supply 30μA
Accuracy ±6°C
Current - Output (Max) 20mA
Analog IC - Other Type ANALOG CIRCUIT
Interface Logic
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 5.5V
Output Type Push-Pull
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G5
Pin Count 5
Output Active High
Base Part Number MAX6502
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.95mm
Supply Voltage 4.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -55°C~135°C
Physical
Surface Mount YES
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
