LTC2996IDD#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 10-WFDFN Exposed Pad
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
THERMOSTAT 20/70DEG OPN DR 10DFN
PDF
/
Buying Options
Total Price: USD $6.17
Unit Price: USD $6.175
≥1 USD $6.175
≥10 USD $5.0673
≥100 USD $4.90865
≥500 USD $4.75
≥1000 USD $4.5923
Inventory: 882
Minimum: 1
-
+
Technical Details
Technical
Current - Supply 200μA
Output Function /OverTemp, /UnderTemp
Sensors/Transducers Type TEMPERATURE SENSOR,ANALOG,VOLTAGE OUTPUT
Housing PLASTIC
Switching Temperature -20°C 70°C
Selectable Hysteresis No
Trip Temperature Threshold Cold Hot
Accuracy ±2°C
Termination Type SOLDER
Power Supplies 3.3V
Output Type Open Drain
Body Breadth 3 mm
Body Length or Diameter 3mm
Pin Count 10
Output Active High, Active Low
Base Part Number LTC2996
Voltage - Supply 2.25V~5.5V
Technology CMOS
Subcategory Other Sensors/Transducers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Utilizes External Sensor
JESD-609 Code e3
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Dimensions
Body Height 0.75mm
Physical
Surface Mount YES
Package / Case 10-WFDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
Compliance
RoHS Status ROHS3 Compliant
