LTC2996HDD#PBF
RoHS
RoHS compliant
RoHS compliantPackage 10-WFDFN Exposed Pad
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
THERMOSTAT 20/70DEG OPN DR 10DFN
PDF
/
Buying Options
Total Price: USD $6.56
Unit Price: USD $6.556
≥1 USD $6.556
≥10 USD $5.92416
≥100 USD $5.648192
≥500 USD $4.904363
≥1000 USD $4.683976
≥3000 USD $4.270693
Inventory: 100
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Physical
Mounting Type Surface Mount
Package / Case 10-WFDFN Exposed Pad
Surface Mount YES
Number of Pins 10
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2012
JESD-609 Code e3
Feature Utilizes External Sensor
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Sensors/Transducers
Technology CMOS
Voltage - Supply 2.25V~5.5V
Base Part Number LTC2996
Output Active High, Active Low
Pin Count 10
Body Length or Diameter 3mm
Body Breadth 3 mm
Output Type Open Drain
Power Supplies 3.3V
Interface I2C, Serial
Termination Type SOLDER
Operating Supply Current 200μA
Nominal Supply Current 200μA
Accuracy ±3°C
Output Function /OverTemp, /UnderTemp
Sensors/Transducers Type TEMPERATURE SENSOR,ANALOG,VOLTAGE OUTPUT
Housing PLASTIC
Switching Temperature -20°C 70°C
Selectable Hysteresis No
Trip Temperature Threshold Cold Hot
Dimensions
Body Height 0.75mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
